Frame
OCLV Mountain Carbon main frame and stays, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, Carbon Armour, shuttle guard, threaded BB, ISCG 05, 34.9 mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160 mm travel
Fork
RockShox ZEB Ultimate Flight Attendant, DebonAir spring, Charger 2.1 RCT3 AXS damper, 1.5" tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 170 mm travel
Shock
RockShox Super Deluxe Ultimate Flight Attendant, 230 mm x 62.5 mm
Max compatible fork travel
180 mm (596 mm axle-to-crown)
Wheel front
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru axle
Wheel rear
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost 148, 12 mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready
Tyre
Size: S , M , ML , L , XL
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Size: S , M , ML , L , XL
Bontrager SE6 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Max tyre size
Frame: 29x2.50"
Shifter
Size: S , M , ML , L , XL
SRAM Eagle AXS, wireless, 12 speed
Size: S , M , ML , L , XL
SRAM Eagle AXS, wireless, 12-
Rear derailleur
SRAM XX1 Eagle AXS
Crank
SRAM XX1 Eagle, Flight Attendant, DUB MTB Wide, 30T alloy ring, 55 mm chain line, 170 mm length
Bottom bracket
SRAM DUB MTB Wide, 73 m, BSA threaded
Cassette
SRAM Eagle XG-1299, 10-52, 12-speed
Chain
SRAM XX1 Eagle, 12-speed
Max. chainring size
Max: 34T, Min 28T
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Size: S
RockShox Reverb AXS, 100 mm travel, wireless, 34.9mm, 340 mm length
Size: M , ML
RockShox Reverb AXS, 150mm travel, wireless, 34.9mm, 440mm length
Size: L , XL
RockShox Reverb AXS, 170mm travel, wireless, 34.9mm, 480mm length
Integrated Bar Stem
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35 mm stem length
Grips
Bontrager XR Trail Pro, alloy lock-on
Head set
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake rotor
Size: S , M , ML , L , XL
SRAM HS2, 6-bolt, 180 mm
Size: S , M , ML , L , XL
SRAM 6-bolt, 200 mm
Brake Set
SRAM Code RSC hydraulic disc
Rotor size
Max brake rotor sizes: Front see fork manufacturer, rear 200 mm
Battery
SRAM eTap battery pack (with charger)
Bag
Bontrager BITS Internal Frame Storage Bag
Weight
M - 14.70 kg / 32.41 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
