Frameset
*Frame
Size: XS , S
Alpha Silver Aluminium, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5 mm QR
Size: M , ML , L , XL , XXL
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
*Fork
Size: XS
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: S
SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M , ML , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Max compatible fork travel
100mm (XS and S: 490mm axle-to-crown, M and up: 509mm axle-to-crown)
Wheels
Skewer rear
152x5 mm QR
Max tyre size
Frame: 29x2.20" (XS & S: 27.5x2.40"), Fork: See manufacturer
Drivetrain
*Shifter
Size: XS , S , M , ML , L , XL , XXL
Shimano EF500, 2-speed
Size: XS , S , M , ML , L , XL , XXL
Shimano Altus EF500, 7-speed
Front derailleur
Shimano Altus M315, 34.9 mm clamp, top swing, dual pull
Rear derailleur
Shimano Tourney TY300
*Crank
Size: XS , S , M
ProWheel TM-CY10, 36/22, 170 mm length
Size: ML , L , XL , XXL
ProWheel TM-CY10, 36/22, 175 mm length
Bottom bracket
VP BC73, 73 mm, threaded cartridge
Cassette
Shimano TZ500, 14-34, 7-speed
Chain
KMC Z7, 7-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x/2x: 34T, 3x: 42T
Components
Saddle
Bontrager Verse Short, stainless steel rails
*Seatpost
Size: XS , S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar
Size: XS , S
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Endurance Comp, lock-on
*Stem
Size: XS , S
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Size: M
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: XL , XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Head set
Semi-integrated, 1-1/8"
*Brake
Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M280 mechanical disc
Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M281 mechanical disc
Brake rotor
Tektro, 6-bolt, 160mm
Weight
Weight
M - 14.60 kg / 32.19 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
