Frame
OCLV Mountain Carbon main frame and stays, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, Carbon Armour, shuttle guard, threaded BB, ISCG 05, 34.9 mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160 mm travel
Fork
Size: S/M/ML/L/XL, RockShox ZEB Ultimate, DebonAir spring, Charger 2.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 170 mm travel
Size: S/M/ML/L/XL, RockShox ZEB Ultimate, DebonAir spring, Charger 2.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 170 mm travel
Shock
NEW RockShox Super Deluxe Ultimate, DebonAir spring, Thru Shaft 3-position damper, 230x62.5 mm
Front wheel
NEW Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear wheel
NEW Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru axle
Front hub
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Rear skewer
Bontrager Switch thru axle
Tyre
Size: S/M/ML/L/XL, Bontrager SE4 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.40"
Size: S/M/ML/L/XL, Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.60"
Tyre part
Bontrager TLR valve, 50 mm
Rim strip
Bontrager TLR
Shifter
SRAM X01 Eagle, 12-speed
Rear derailleur
SRAM X01 Eagle
Crank
Size: S, SRAM X01 Eagle, DUB, 30T alloy ring, Boost (55 mm chain line), 170 mm length
Size: M/ML/L/XL, SRAM X01 Eagle, DUB, 30T alloy ring, Boost (55 mm chain line), 175mm length
Bottom bracket
SRAM DUB, 73 mm, BSA threaded
Cassette
SRAM Eagle XG-1275, 10-52, 12-speed
Chain
SRAM GX Eagle, 12-speed
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Size: M/ML, Bontrager Line Elite Dropper, 150 mm travel, internal routing, 34.9 mm, 440 mm length
Size: L, Bontrager Line Elite Dropper, 170 mm travel, internal routing, 34.9 mm, 485 mm length
Size: XL, Bontrager Line Elite Dropper, 200 mm travel, internal routing, 34.9 mm, 550 mm lengthSize: S, Bontrager Line Elite Dropper, 100 mm travel, internal routing, 34.9 mm, 345 mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 820mm width
Grips
Bontrager XR Trail Pro, alloy lock-on
Stem
Bontrager Line Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 35 mm length
Head set
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake
SRAM Code RSC hydraulic disc
Brake rotor
Size: S/M/ML/L/XL, SRAM CenterLine, 6-bolt, round-edge, 180mm
Size: S/M/ML/L/XL, SRAM CenterLine, 6-bolt, round-edge, 200 mm
Bag
Bontrager BITS Internal Frame Storage Bag
Weight
M - 14.12 kg / 31.14 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
