Frame Size: XS, S
Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Frame Size: M, L, XL
Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork Size: XS
SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 80 mm travel
Fork Size: S, M, L, XL
SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm thru axle, 120 mm travel
Max Compatible Fork Travel
120mm (526mm axle-to-crown), XS: 80mm (492mm axle-to-crown)
Hub Front
Formula DC-511, 6-bolt, Boost110, 15 mm thru axle
Hub Rear
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12 mm thru axle
Skewer Rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre Size: XS, S
Bontrager XR3 Comp, wire bead, 30 tpi, 27.5x2.35"
Tyre Size: M, L, XL
Bontrager XR3 Comp, wire bead, 30 tpi, 29x2.30"
Max Tyre Size
Frame: 29x2.60" or 27.5x2.80" (XS & S: 27.5x2.60"), Fork: See manufacturer
Battery
Bosch PowerTube 625Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
Controller
Bosch Intuvia 100, smart system
Computer
Bosch LED remote, smart system
Motor
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm
Shifter
Shimano Deore M4100, 10 speed
Rear Derailleur
Shimano Deore M5120, long cage
Crank
FSA Bosch CK-220, 36T ring, 165 mm length
Chainring
FSA, 36T, steel
Cassette
Shimano Deore M4100, 11-46, 10-speed
Chain
KMC X10, 10-speed
Pedal
VP-536 nylon platform
Max. Chainring Size
1x: 38T
Saddle
Bontrager Commuter Comp
Seatpost Size: XS, S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Seatpost Size: M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Seatpost Size: L, XL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar Size: XS, S
Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Handlebar Size: M, L, XL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem Size: XS
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Stem Size: S, M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Stem Size: L, XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake Rotor
Tektro, 6-bolt, 203 mm
Brake Set
Tektro HD-M275 hydraulic disc
Rotor Size
Max brake rotor sizes - Frame: 203mm, Fork: see fork manufacturer
Weight
M - 24.53 kg / 54.08 lbs
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
